Description

Main Features

Operating amperage (Ie): 63 A

Operating voltage (Ue): 690 V

Short-circuit-limited current: 8 kA

Cross-section of flexible conductor: 16-50 mm²

Torque: 2.4 Nxm

Enclosure material: self-extinguishing fiberglass polyester

Material of contacts: silver alloy

Complying with standards: IEC 60947-3

Accessories

White front plate: AK1800104

White arrow-type switch: AK1000016

Padlock switch: AK1200526

Plate for fixing on DIN rail: AK0100007

Plate for fixing on panel: AK0000006

IP65 airtight seal: AK2220006

Prolonged shaft set: AK1730006

Descargas

Catálogo – Interruptores Rotativos a Levas

Certificado IRAM – Interruptores Rotativos a Levas

Instructivos

Instructions will de available shortly.
