C-curve, 32 A, (4.5 kA) 4-P thermomagnetic circuit breaker

C-curve, 32 A, (4.5 kA) 4-P thermomagnetic circuit breaker

ACB232C4,5

837.206

SKU: ACB232C4,5 | 837.206 Category:

Description

Main Features

Dimensions

  • Length: 81 mm
  • Height: 72 mm
  • Width: 71.2 mm

In compliance with: IEC 60898

Technical Data

Fixing support: NS-35 symmetrical DIN rail

Number of poles: 4

Rated voltage: 240/415 V AC

Rated current: 32 A

Residual current: 4.5 kA

Curve: C

Cress-section of flexible conductor: 1 to 25 mm2

Torque: 1.7 to 2.5 Nxm

Operating temperature: -5 °C to +40 °C

Accessories

Busbar: PCZ 4P

Busbar cover: cover PCZ 4P

Cable connector: 817.900

End: EKN1

Lockout with interlocking tabs: TC-01

Screwdriver: DES-06

Descargas

Catalog

Certificate UL

Instructivos

Instructions will be available shortly.
