Description

Main Features

Dimensions

• Length: 90 mm
• Height: 65 mm
• Width: 72 mm

In compliance with: IEC 61000-4-2/4-3/4-4/4-5/4-6/4-8/4-11; CSPR 11/14-1; IEC 6100-3-3 2011/65/EU; IEC 60068-2-1/2-2/2-6/2-27

Technical data

Fixing support: NS-35 symmetrical DIN rail

Input voltage: 12 or 24 V DC

Input voltage range: -20% to 10% of nominal voltage

Power consumption: 5 W

Digital inputs: 8 (6 digital and 2 digital/analog)

Analog inputs: 2 (0-10 V)

Outputs: 4 NO relays 8 A / 240 V AC 5 A / 30 V DC

Relay expansion: Up to 3 modules (48 input/output)

Programming: LADDER (Soft Logic included)

Visual indicator: Backlight LCD display

Operation temperature: -10 to 55° C

Relative humidity: 0,85

IP degree of protection: IP-20

Maximum cable cross-section: 4 mm²

Torque: 0,5 Nxm

Enclosure material: self-extinguishing UL94-V0

Accessories

Screwdriver: DES-03

Descargas

CAD 2D

Catalog

Instructivos

Instructions will be available shortly.
